| MODEL |
DIPD-5101 |
| Input Video Port |
2 x RJ-45; 1 x Optical |
| Input Video Type |
IP Stream |
| Input Resolutions |
3840 x 2160p@24/25/30/50/60Hz 4:4:4, |
| 1920 x 1200@50/60Hz, 2400x1350p@60Hz, |
| 1920 x 1080p@24/25/30/50/60/100/120Hz, |
| 1920 x 1080i@50/60Hz, 1680 x 1050@60Hz, |
| 1600 x 1200@60Hz, 1600 x 900@60Hz, |
| 1400 x 1050@60Hz, 1440 x 900@60Hz, |
| 1366 x 768@60Hz, 1360 x 768@60Hz, |
| 1280 x 1024@60Hz, 1280 x 960@60Hz, |
| 1280 x 800@60Hz, 1280 x 768@60Hz, |
| 1280 x 720p@60/100/120Hz, 1024 x 768@60Hz, |
| 800 x 600@60Hz, 720 x 576p@50Hz, |
| 720 x 480p@60Hz, 640 x 480p@60Hz |
| Output Video Port |
1 x HDMI Type A (19 Pins) |
| Output Video Type |
HDMI 2.0, HDCP 2.2/2.3 |
| Output Resolutions |
Up to 3840 x 2160p@60Hz 4:4:4 |
| Input/Output Video Signal |
0.5~1.2 V p-p |
| Input/Output DDC Signal |
5V p-p (TTL) |
| Video Impendence |
100Ω |
| End-to-End Latency |
For 4K@60Hz: |
| Normal mode: 17ms |
| Ultra Low Latency mode: 4ms |
| Maximum Data Rate |
18Gbps (6Gbps per color) |
| Maximum Pixel Clock |
600MHz |
| Input Audio Port |
2 x RJ-45; 1 x Optical; 1 x S/PDIF IN |
| Output Audio Signal |
AUDIO OUT: Analog |
| Dante Audio Type |
LPCM 2.0, 44.1/48/88.2/96KHz |
| Control Method |
Telnet API; IP Controller |
| Operating Temperature |
32°F ~ 113°F (0°C ~ 45°C), 10% ~ 90%, non-condensing |
| Storage Temperature/ Humidity |
-4°F ~ 158°F (-20°C ~ 70°C), 10% ~ 90%, non-condensing |
| Power |
12V DC 3A; PoE+ |
| Power Consumption |
21W (Max) |
| ESD Protection |
Human body model: |
| ±8kV (air-gap discharge)/±4kV (contact discharge) |
| Dimensions (W x H x D) |
8.46'' x 0.98'' x 6.30'' (215mm x 25mm x 160mm) |
| Net Weight |
2lbs (0.91kg) |
