The DWS-AD50F is a passive 1-to-2 Antenna Splitter designed for integrating two sets of wireless receiver antennas covering the UHF 500-960 MHz frequency range. This splitter ensures stable and reliable signal distribution, making it ideal for various professional audio applications.
| Model | DWS-A50F |
| Frequency range | UHF 500 – 960 MHz |
| Impedance | 50 Ω |
| Gain | Attenuation 3.5 dB (typ.) |
| Connector | TNC female (1 input + 2 outputs) or |
| BNC female (1 input + 2 outputs) | |
| Dimensions (mm) | 99 × 40 × 18.5 |
| Weight (g) | 189 |
