FEATURES

•       Daisy-Chain connectivity uses a single cable to connect and manage up to 64 audio channels without and extension, with expansion module (DCS-EXM) connect and manage up to 5200 audio channels.
•       Independent microphone operation ensures each microphone functions separately for clear and efficient communication.
•       Automatic audio adjustments maintain balanced and high-quality sound with built-in optimization.
•       Multi-room management supports multiple rooms and allows seamless room combination for larger meetings.
•      Fail-safe operation continues functioning smoothly even if some components are replaced or fail.
•       Noise reduction and echo prevention minimize background noise and prevent audio echo for clear speech.
•      Direct audio recording allows direct recording of meetings and conferences.
•       Scalability and expansion support additional speakers and integrate with other systems for enhanced flexibility.
•       Reliable and flexible conference solution provides a stable, adaptable setup for various conference needs.

FUNCTIONS

● Compliance with IEC 60914, GBT 15381-94

● Connect with DCS-EXM full-digital extension main unit, it can expand to 5200 discussion units

● "Daisy-Chain Network" connection and the system assigned to each unit independently ID to avoid ID conflict.

● Only wired discussion units can connect to the controller, fast and easily to adding delegate of meetings.

● Supports 4-way CU/DU connection for microphone units.

● 2 channel audio input, XLR or RCA type, for local audio input or remote video-conferencing input.

● Maximum 8-channel audio output, XLR, RCA or Phoenix type, can be connected to simultaneous interpretation output or partitioned output.

● Add the audio input box, the system can be connected to other condenser microphones or dynamic microphones, more choices for users.

● Built-in multi-way internal communication function.

● TCP/IP connection between controller and PC

● RS232 central control, realize microphone switch, priority, volume and other controls.

● RS232 or RS485 to send the PELCO/VISCA protocol to realize camera auto-tracking function.

● Hot plug-and-play, and auto-recovery function.

● Wide range of voltage from 100V~240VAC
